CURVE AJQ
AirCURVE AJQ is a joystick transmitting unit that can house up to 3 multi-axis joysticks.
Thanks to the AIR Series technology, it’s ideal for the remote control of overhead cranes, boat trailers, compactor presses, gantry cranes and many other applications, in single or multiple-unit configurations.
CURVE has a FHSS bi-directional radio with a frequency band of 870 / 915 MHz. A data feedback function provides the user with important machine status information on an optional customizable 2.8" color TFT LCD graphic display.
Accessories
Waist belt
Extractable NiMH or Li-Ion battery and charger
Actuators
Potentiometer
Rotary switch
Toggle switch
Pull-to-operate toggle switch
Toggle switch with security cap
Side pushbutton
Options
Cable Control (Tether Cable)
The cable control allows connection of the cable station to the base station via cable, replacing the wireless connection with a wired connection.
Zero-G sensor
The Zero-G sensor activates in case of impact, throwing, rolling, falling from a height of over 1 meter, or tilting beyond a preset angle of the transmitting unit.
IR Sensor
Used to restrict the operating area of the remote control and operator.
2.8" TFT LCD display (320x240 pixels, 65536 colors)
The display is equipped with 16 LEDs and includes five buttons for interaction. An optional encoder is also available to facilitate navigation. Suitable for both indoor and outdoor environments.
32 LED Matrix
32 diagnostic LEDs are available. The light intensity can be customized, and a NIGHT & DAY mode is also available.
External buzzer
The buzzer is used to emit sound signals in certain situations.
Removable mechanical ignition key
If the portable station does not have Key ID 0-1, it is possible to install the removable mechanical ignition key.
